This installation demonstrates a fender recess inlay on a black 1997-2004 Chevrolet Corvette.
The video highlights why stretching a single sheet into deep recesses can cause vinyl to lift and fail. Instead of forcing the film, creating a multi-piece inlay provides full coverage and long-lasting durability.
Step-by-Step Inlay Method
To complete the fender recess, follow these installer steps:
- Lay down knifeless tape along the inner lines of the recess.
- Position a separate piece of material and work it into place using a wrap glove.
- Pull the knifeless tape through the film and discard the excess pieces.
- Glass out the bottom section of the fender and remove all trapped air.
- Heat the inlaid area, press firmly with your thumb around the seam, and free cut with an eighth-inch overlap before trimming the final edge.
Working the cut section carefully into the recess keeps seams discreet and prevents tension buildup. Aura Vinyl vinyl wrap uses a cast polymer hybrid film with German-made adhesive, making it pliable and easy to reposition across complex body panels.
FAQ
Why should you use an inlay instead of stretching vinyl into a deep recess?
Forcing vinyl wrap into a complex shape causes excessive tension, which makes the material more likely to lift and fail. An inlay provides proper coverage without overstretching the film.
How much seam overlap should you leave on a vinyl inlay?
The installer recommends giving yourself about an eighth of an inch of overlap when making your cut over the inlay.
How do you set the vinyl around the inlay edge before cutting?
Heat up the inlaid area and use your thumb to lock the material in all around the inlay before cutting the overlap.
