This tutorial demonstrates vinyl wrap panel layout on a dark gray 2013 to 2020 Subaru BRZ. The video shows how to cut out the pillar, quarter panel, door, and side skirt from a single large sheet of material instead of cutting each panel individually. To start, cut a wide strip off the top edge if your car has an added-on side skirt. Next, take the back side of a snitty tool to press an etch line into the vinyl between the door and the quarter panel, and between the door and the side skirt. This creates a clear visual guideline so you avoid cutting blind. Cut the pillar section straight, as the vinyl will curve to match the bend of the roofline during installation. Because this car uses a C-cut where the pillar, quarter panel, and side skirt stay connected, follow the pillar cut directly into the etched line. Maintain about three inches of excess material on both sides of every cut. This extra room allows you to shift the film in either direction while positioning it on the car. After the door piece is removed, align the connected pillar, quarter panel, and side skirt to verify placement before installing the material. Aura Vinyl vinyl wrap uses a cast polymer hybrid construction with German-made adhesive and a PET backing for smooth application.
FAQ
What is a C-cut in car wrapping?
A C-cut connects the pillar, quarter panel, and side skirt into a single piece cut from the vinyl sheet.
How much extra vinyl should you leave when cutting panels?
A good rule of thumb is to leave three inches of excess material on either side of the cut line. This gives you enough material to shift the film either way during installation.
How do you make an etch line on vinyl wrap?
You can create an etch line between panels by running the back side of a snitty tool along the body gap. This provides a clear guideline to follow so you do not cut blind.
